| Capacities | ||
|---|---|---|
| Gas Tank | 20 gallons | -- |
| Cooling system | w/o heater: 20.5 quarts | with heater: 21.5 quarts |
| Differential | 4.75 pints | -- |
| Engine Crankcase (refill) | 5 quarts | -- |
| Engine Crankcase (w filter) | 6 quarts | -- |
| Hydramatic (refill pan not removed) | 9.75 quarts | -- |
| Hydramatic (refill pan removed) | 11.25 quarts | -- |
| Light Specifications | ||
| Lamp | Candle power | Bulb # |
| Headlights | 50 - 40 Watts | 5400 |
| Instrument cluster | 2 c.p. | 57 |
| Stop and tail lights | 4 - 32 | 1034 |
| Dome light | 15 | 1004 |
| Rear license | 3 | 67 |
| Glove compartment | 2 | 57 |
| Beam indicator | 1 | 53 |
| Underhood | 6 | 89 |
| Rear compartment | 6 | 89 |
| Back-up | 32 | 1073 |
| Ignition switch | 2 | 57 |
| Radio dial | 2 | 57 |
| Turn signal indicator | 2 | 57 |
| Electric clock | 2 | 57 |
| Parking (with turn signal) | 4 - 32 | 1034 |
| Ash tray | 1 | 53 |
| Courtesy | 6 | 90 |
| Fuse Specifications | ||
| Fuse | Fuse Type and Amperes | Location |
| Electric clock | AGA 1 | Fuse block beh.instrum. |
| Courtesy, dome, stop, rear seat | AGC 25 | Fuse block beh.instrum. |
| Fuel, temp., hand brake, back-up, turn, glove box, under hood, ignition, tail, trunk | SFE 9 | Fuse block beh.instrum. |
| Radio | AGW 7.5 | Fuse block beh.instrum. |
| Heater | SFE 20 | Fuse block beh.instrum. |
| Air conditioner (if so) | AGC 25 | Fuse block beh.instrum. |
| Electric windows, antenna | SFE 20 | auxiliary fuse block |
| Head lights | Circuit breaker | -- |
| Instrument cluster, ash tray, Clock light | SFE 2 | On headlight switch |
| Cigar lighter | SFE 20 | Beh.cigar lighter |
